| LCD Description | |
|---|---|
| Model | SSE17 |
| Manufacturer | |
| Recovered from | Uniden SSE17 phone |
| Board IDs | PE-2155BA |
| LCD type | positive |
| Polarizer type | transflective |
| Columns | 132 pixels |
| Rows | 48 pixels |
| Char matrix | 5×16, 16×32 |
| Driver IC | |
| Backlight | - |
| Arduino driver | |
| Connector | pins |
| Num Pins | 18 |
| Pin spacing | 1.5mm |
| Connector pin-out | Arduino test rig | ||
|---|---|---|---|
| Pin# | Label | Description | Pin |
| 1 | |||
| 2 | |||
| 3 | |||
| 4 | |||
| 5 | |||
| 6 | |||
| 7 | |||
| 8 | |||
| 9 | |||
| 10 | |||
| 11 | |||
| 12 | GND | ||
| 13 | +3.3V | ||
| 14 | Si | ||
| 15 | Clk | ||
| 16 | C/D | ||
| 17 | /Reset | ||
| 18 | /CS | ||
