LCD module data
Numeric
Character
Mixed
- ≡ Uniden FP203 ✘
- ≡ Uniden FP204 ✘
- ≡ VIP89Z G-Code ✘
Graphic
key: ≡ parallel, ↔ serial, ~ LVDS, _ unknown, ✘ discarded as not useful
| LCD Description | |
|---|---|
| Model | Alcatel 4019 |
| Manufacturer | Alcatel |
| Recovered from | Alcatel 4019 phone |
| Board IDs | 1AB063770003 ALCATEL-100*8 dots, 611A/PC419HIN01G |
| LCD type | Positive |
| Polarizer type | Reflective |
| Columns | 20 |
| Rows | 1 |
| Char matrix | 5×8 |
| Driver IC | |
| Backlight | - |
| Arduino driver | |
| Connector | PCB flex cable |
| Num Pins | 10 |
| Pin spacing | 1mm |
| Module size | mm |
| Connector pin-out | Arduino test rig | |||
|---|---|---|---|---|
| Pin# | IC pin | Label | Pin | colour |
| 1 | ||||
| 2 | ||||
| 3 | ||||
| 4 | ||||
| 5 | ||||
| 6 | ||||
| 7 | ||||
| 8 | Vdd | 5V | ||
| 9 | Vo? | 0.93V | ||
| 10 | GND | |||
