| LCD Description | |
|---|---|
| Model | Ltl Acorn 5120a |
| Manufacturer | |
| Recovered from | Ltl Acorn 5120a trail camera |
| Board IDs | UFO 20140530 PC |
| LCD type | 16.7 M colour |
| Polarizer type | |
| Columns | 480 |
| Rows | 234 |
| Char matrix | - |
| Driver IC | |
| Backlight | - |
| Arduino driver | |
| Connector | PCB flex |
| Num Pins | 40 |
| Pin spacing | “ |
| Module size | 48 x 35.69 mm |
| Connector pin-out | Arduino test rig | |||
|---|---|---|---|---|
