| LCD Description | |
|---|---|
| Model | VIP89Z G-Code scanner |
| Manufacturer | Gemstar |
| Recovered from | G-Code scanner |
| Board IDs | V.UF10E 1EC004090 |
| LCD type | |
| Polarizer type | |
| Columns | 2 numerals, 11 alphanumeric |
| Rows | 1 |
| Char matrix | |
| Driver IC | Gemstar-350 9241KX009 |
| Backlight | - |
| Arduino driver | |
| Connector | PCB flex cable |
| Num Pins | 36 |
| Pin spacing | 0.05“ |
